Victron Telecom Batteries Description:
AGM technology
AGM stands for Absorbent Glass Mat. In these batteries the electrolyte is absorbed into a glass-fibre mat between the plates by capillary action.
Low self-discharge
Because of the use of lead calcium grids and high purity materials, Victron VRLA batteries can be stored during long periods of time without recharge. The rate of self-discharge is less than 2% per month at 20°C. The self-discharge doubles for every increase in temperature with 10°C.
Low internal resistance
Accepts very high charge and discharge rates.
High cyclic life capability
More than 500 cycles at 50% depth of discharge.
Capacity | 115Ah | 165Ah | 200Ah |
---|---|---|---|
Capacity 1 / 3 / 5 / 10 / 20 hours (% of nominal) 60 / 75 / 82 / 91 / 100 (@ 70ºF/25ºC, end of discharge 10,5V) | 60 / 75 / 82 / 91 / 100 | 60 / 75 / 82 / 91 / 100 | 60 / 75 / 82 / 91 / 100 |
Capacity 10 / 20 / 30 / 40 minutes (% of nominal) 33 / 44 / 53 / 57 (@ 70ºF/25ºC, end of discharge 9,6V) | 33 / 44 / 53 / 57 | 33 / 44 / 53 / 57 | 33 / 44 / 53 / 57 |
Nominal capacity (77ºF/25ºC, 10,5V) | 115Ah | 165Ah | 200Ah |
Cold Cranking Amps @ 0ºF/-18ºC | 1000 | 1500 | 1800 |
DIN cold start current (A) @ 0ºF/-18ºC | 600 | 900 | 1000 |
Short Circuit Current (A) | 3500 | 5000 | 6000 |
Reserve Capacity (minutes) | 200 | 320 | 400 |
Shelf life @ 70ºF/20ºC | 1 year | 1 year | 1 year |
Absorption voltage (V) @ 70ºF/20ºC | 14,4 – 14,7 | 14,4 – 14,7 | 14,4 – 14,7 |
Float voltage (V) @ 70ºF/20ºC | 13,6 – 13,8 | 13,6 – 13,8 | 13,6 – 13,8 |
Storage voltage (V) @ 70ºF/20ºC | 13,2 | 13,2 | 13,2 |
Float design life @ 70ºF/20ºC | 12 years | 12 years | 12 years |
Cycle design life @ 80% discharge | 500 | 500 | 500 |
Cycle design life @ 50% discharge | 750 | 750 | 750 |
Cycle design life @ 30% discharge | 1800 | 1800 | 1800 |
Dimensions (lxwxh, mm) | 395 x 110 x 293 | 548 x 105 x 316 | 546 x 125 x 323 |
Dimensions (lxwxh, inches) | 15.37 x 4.33 x 11.53 | 21.57 x 4.13 x 12.44 | 21.49 x 4.92 x 12.71 |
Weight (kg/pounds) | 35kg/77lbs | 49kg/88lbs | 60kg/132lbs |
