The VE Transfer Switch automatically switches between different power sources: between a generator and shore power, between an inverter and a generator or between an inverter and shore power.

Read more

Have a question?

Talk with a technical expert.

Victron VE Transfer Switch In 5kVA Description:

The VE Transfer Switch automatically switches between different power sources: between a generator and shore power, between an inverter and a generator or between an inverter and shore power.
The VE Transfer Switch has two inputs and one output, it automatically transfers the available AC power to the output.

Specification 5kVA (COS 0) 10kVA (COS 0)
Nominal voltage 200 - 250Vac, single-phase
Nominal frequency 50 – 60Hz
Nominal current input 1 20A 40A
Nominal current input 2 20A 40A
Nominal output current 20A 40A
Maximum electromotor (air-conditioner) power 1.3kW 8kW
Power consumption input 1 6VA 6VA
Power consumption input 2 0VA 0VA
Transfer time by closing contacts 10 - 20ms 10 - 20ms
Transfer time by opening contacts 5 - 20ms 5 - 20ms
Contacts delay input 1 Approximately 10s (adjustable)
Auxiliary contact 200 - 240Vac, 20A, cos phi = 1
GENERAL
Operating temperature -5°C to +60°C
Maximum humidity (non-condensing) 95%
Miniature circuit breaker (MCB) Not included - installation dependent
Earth leakage breakers (RCD) Not included - installation dependent
ENCLOSURE
Protection category IP 54
Colour RAL 7035
Dimensions (mm) 175 x 215 x 120 175 x 215 x 120
Weight (kg) 1.85 1.65
  • Automatically switches between two power sources, such as a generator, shore power, or inverter, to ensure continuous power availability.
  • Nominal voltage range of 200-250V AC, supporting single-phase systems with reliable performance.
  • Fast transfer time with contacts closing within 10-20 milliseconds, minimizing interruptions to connected loads.
  • Adjustable delay for input 1 (approximately 10 seconds) to ensure stable operation before switching.
  • High-grade IP54-rated enclosure, providing protection against dust and limited water exposure, suitable for various environments.
  • Equipped with auxiliary contacts compatible with Digital Multi Control (DMC) panel for enhanced system integration.
